KnockoutJS custom binding for Quicksand

This plugin has been moved into GitHub. And thanks to some updates to Quicksand, it now works with the latest versions of jQuery, Quicksand, and KnockoutJS.

Lately I've been experimenting with KnockoutJS, a JavaScript framework for streamlining client-side data and UI updates. I've found it wonderfully easy to implement Knockout's out-of-box functionality and obsolete tons of my custom code. This conversion was helped by Knockout's thorough documentation and numerous working examples. But I soon had the desire to integrate Knockout with Quicksand, a jQuery plugin for animating list sorts and filters. This quickly proved difficult, probably because I'm still new to Knockout, but with help from the Knockout forums I eventually created a custom binding to apply Quicksand animations to a Knockout observableArray. No one else has published such a binding so I'm sharing mine for others' benefit. But beware that it may not handle every circumstance you throw at it.

Overview

The quicksand custom binding mirrors Knockout's foreach (docs), which displays and tracks changes to an observableArray (docs). Simply put, the quicksand binding aims for the same functionality but with fancier animations. The foreach binding can also be added to a template (docs) binding for greater flexibility. So I've created a quicksandTemplate to mirror that functionality as well. The quicksandTemplate binding depends on functions in the quicksand binding.

Code

Here is the JavaScript code for the custom bindings, written against KnockoutJS 2.2.1.

ko.bindingHandlers.quicksand = {
	/**
	 * Create the hidden working space to facilitate the Quicksand animation.
	 *
	 * @param Element element  The DOM element with the KnockoutJS data bind.
	 * @param jQuery $repeatingElements  The HTML used to render each array element.
	 * @return jQuery  The Quicksand working space.
	 */
	createWorkspace: function(element, $repeatingElements) {
		// Generate a unique ID for the DOM element that will facilitate the Quicksand animation.
		var quicksandWorkspaceId = 'ko-quicksand-' + new Date().getTime();
		// Store the unique ID for reference during the "update" event.
		ko.utils.domData.set(
			element,
			'ko-quicksand-workspace-id',
			quicksandWorkspaceId,
		);

		// Look up the outermost element type in the rendering template and store it for reference during the "update" event.
		ko.utils.domData.set(
			element,
			'ko-quicksand-container-tag',
			$repeatingElements[0].tagName,
		);

		// Create the hidden DOM element that will facilitate the Quicksand animation.
		var $quicksandWorkspace = jQuery('<div/>', {
			id: quicksandWorkspaceId,
			style: 'display: none',
		});
		// Append it to the DOM for use during the "update" event.
		$quicksandWorkspace.appendTo('body');

		return $quicksandWorkspace;
	},
	/**
	 * Get the hidden working space used to facilitate the Quicksand animation.
	 *
	 * @param Element element  The DOM element with the KnockoutJS data bind.
	 * @return jQuery  The Quicksand working space.
	 */
	getWorkspace: function(element) {
		return jQuery(
			'#' + ko.utils.domData.get(element, 'ko-quicksand-workspace-id'),
		);
	},
	/**
	 * Get the name of the HTML tag that encompasses each array element.
	 *
	 * @param Element element  The DOM element with the KnockoutJS data bind.
	 * @return string  The container tag name.
	 */
	getContainerTag: function(element) {
		return ko.utils.domData.get(element, 'ko-quicksand-container-tag');
	},
	init: function(
		element,
		valueAccessor,
		allBindingsAccessor,
		viewModel,
		bindingContext,
	) {
		// Look up the provided template for rendering each element of the array.
		var $repeatingElements = jQuery(element).children();

		var $quicksandWorkspace = ko.bindingHandlers.quicksand.createWorkspace(
			element,
			$repeatingElements,
		);

		// Populate the workspace with the rendering template so it mirrors the contents of element.
		$repeatingElements.clone().appendTo($quicksandWorkspace);

		// Register the hidden DOM element for updates by Knockout.
		return ko.bindingHandlers['foreach']['init'](
			$quicksandWorkspace[0],
			valueAccessor,
			allBindingsAccessor,
			viewModel,
			bindingContext,
		);
	},
	update: function(
		element,
		valueAccessor,
		allBindingsAccessor,
		viewModel,
		bindingContext,
	) {
		// Unwrap the observable to subscribe to updates.  Check if the data property is implicit or explicit.
		ko.utils.unwrapObservable(
			valueAccessor().hasOwnProperty('data')
				? valueAccessor().data
				: valueAccessor(),
		);

		var $quicksandWorkspace = ko.bindingHandlers.quicksand.getWorkspace(
			element,
		);

		// Update the hidden DOM element using Knockout.
		ko.bindingHandlers['foreach']['update'](
			$quicksandWorkspace[0],
			valueAccessor,
			allBindingsAccessor,
			viewModel,
			bindingContext,
		);

		var quicksandOptions = valueAccessor().hasOwnProperty('options')
			? valueAccessor().options
			: {};

		// Run Quicksand to copy the contents of the hidden DOM element to the visible element using the Quicksand animation.
		jQuery(element).quicksand(
			$quicksandWorkspace.children(
				ko.bindingHandlers.quicksand.getContainerTag(element),
			),
			quicksandOptions,
		);
	},
};

ko.bindingHandlers.quicksandTemplate = {
	init: function(
		element,
		valueAccessor,
		allBindingsAccessor,
		viewModel,
		bindingContext,
	) {
		// Look up the provided template for rendering each element of the array.
		if (allBindingsAccessor().quicksandTemplate.hasOwnProperty('name')) {
			// The repeating template is defined in a named <script> block.
			var $repeatingElements = jQuery(
				jQuery.parseHTML(
					jQuery.trim(
						jQuery('#' + allBindingsAccessor().quicksandTemplate.name).html(),
					),
				),
			);
			var $quicksandWorkspace = ko.bindingHandlers.quicksand.createWorkspace(
				element,
				$repeatingElements,
			);
		} else {
			// The repeating template is the children of element.
			var $repeatingElements = jQuery(element).children();

			var $quicksandWorkspace = ko.bindingHandlers.quicksand.createWorkspace(
				element,
				$repeatingElements,
			);

			// Populate the workspace with the rendering template so it mirrors the contents of element.
			$repeatingElements.clone().appendTo($quicksandWorkspace);
		}

		// Register the hidden DOM element for updates by Knockout.
		return ko.bindingHandlers['template']['init'](
			$quicksandWorkspace[0],
			valueAccessor,
			allBindingsAccessor,
			viewModel,
			bindingContext,
		);
	},
	update: function(
		element,
		valueAccessor,
		allBindingsAccessor,
		viewModel,
		bindingContext,
	) {
		// Unwrap the observable to subscribe to updates.
		ko.utils.unwrapObservable(valueAccessor().foreach);

		var $quicksandWorkspace = ko.bindingHandlers.quicksand.getWorkspace(
			element,
		);

		// Update the hidden DOM element using Knockout.
		ko.bindingHandlers['template']['update'](
			$quicksandWorkspace[0],
			valueAccessor,
			allBindingsAccessor,
			viewModel,
			bindingContext,
		);

		var quicksandOptions = valueAccessor().hasOwnProperty('options')
			? valueAccessor().options
			: {};

		// Run Quicksand to copy the contents of the hidden DOM element to the visible element using the Quicksand animation.
		jQuery(element).quicksand(
			$quicksandWorkspace.children(
				ko.bindingHandlers.quicksand.getContainerTag(element),
			),
			quicksandOptions,
		);
	},
};

The logic above is actually pretty simple.

  1. Create a hidden container that mirrors the content of the data-bound element.
  2. Wire the hidden container, rather than the data-bound one, to be updated by Knockout.
  3. Whenever the hidden container changes, synchronize its contents with the data-bound element using Quicksand.

Usage

The Quicksand custom bindings aim to support the same syntax as their built-in counterparts.

<ul data-bind="quicksand: arrayName">
	<li data-bind="text: elementPropertyName"></li>
</ul>
<ul data-bind="quicksand: { data: arrayName }">
	<li data-bind="text: elementPropertyName"></li>
</ul>

The optional options attribute can specify Quicksand parameters.

<ul
	data-bind="quicksand: { data: arrayName, options: { quicksandOption: value } }"
>
	<li data-bind="text: elementPropertyName"></li>
</ul>
<ul
	data-bind="quicksandTemplate: { foreach: arrayName, options: { quicksandOption: value } }"
>
	<li data-bind="text: elementPropertyName"></li>
</ul>
<ul
	data-bind="quicksandTemplate: { foreach: arrayName, name: 'template-id', options: { quicksandOption: value } }"
></ul>
<script type="text/html" id="template-id">
	<li data-bind="text: elementPropertyName"></li>
</script>

And to see the bindings in action, check out this jsFiddle based on Knockout's "animated transitions" example.
